Battery Capacity: |
314Ah |
Battery Type: |
LFP |
lnstallation: |
Cabinet Holding |
Waranty: |
5 or 10 years(optional) |
Wholesale 314Ah High Voltage Lithium Battery Supplier for Commercial and Utility ESS
The 314Ah High Voltage Lithium Battery is a high-capacity energy storage solution for commercial and industrial solar systems. Built with reliable LFP technology, it offers high efficiency, long cycle life, intelligent BMS protection, and stable performance for backup power and renewable energy storage applications.
Note: Please read the safety and installation manual before using the product. We reserve the right of finalinterpretation.
The specifications in this datasheet are subject to change without notice.
Battery Features
- Original A-grade lithium iron phosphate battery cell has high safety and reliability
- Intelligent integrated BMS, all-round protection strategy and fault detection
- Modular design, parallel expansion, flexible choice of voltage and capacity
- Large capacity, high charging and discharging efficiency, more than 6000 cycle life
- Built-in fire extinguishing device, automatically deal with ultra-early warning thermal runaway status
- Bottom tripod design, standard cabinet for easy installation and easy maintenance
- Built-in BMS intelligent protection function, compatible with leading high-voltage inverters
- Achieving the maximum efficiency through the high-voltage series connection, with high-power emergency backup and off-grid functions
- ON/OFF switch control output
- LCD display, dynamic display of system operating status data
Product Description
| Product Type | HVM96S314BL-U | HVM128S314BL-U | HVM160S314BL-U | HVM192S314BL-U |
| Number of Modules | 6 | 8 | 10 | 12 |
| Battery Capacity | 314Ah | 314Ah | 314Ah | 314Ah |
| Battery Energy | 96.46KWh | 128.61KWh | 160.76KWh | 192.92KWh |
| Size (L×W×H) mm | 550×811×2080 | 1100×811×1570 | 1100×811×1800 | 1100×811×2080 |
| Weight | 830Kg | 1100Kg | 1355Kg | 1480Kg |
| Standard Charge Current | 100A | 100A | 100A | 100A |
| Standard Discharge Current | 200A | 200A | 200A | 200A |
| Features | ||||
| Battery Type | LFP | |||
| Cycle Life | ≥ 6000 times @ 80% DOD, 25°C | |||
| Nominal Voltage | 307.2V | 409.6V | 512V | 614.4V |
| Operating Voltage Range | 160-584V | |||
| IP Protection | IP21 | |||
| Installation | Cabinet Holding | |||
| Charging Temperature | 0~60°C | |||
| Discharge Temperature | -10~60°C | |||
| Conventional | ||||
| BMS Monitoring Parameters | SOC, System voltage, current, cell voltage, cell temperature, PCBA temperature measurement | |||
| Communication Port | RS485/CAN | |||
| Warranty | 5 or 10 years (optional) | |||
Product Advantages
Lower Total Cost of Ownership
Long battery lifespan and minimal maintenance reduce operational costs throughout the project lifecycle.
Flexible Capacity Expansion
Modular battery design allows future expansion without replacing the entire energy storage system.
Stable Performance
Maintains reliable output under various operating conditions with excellent charge/discharge consistency.
Smart Energy Management
Compatible with intelligent EMS platforms for optimized charging strategies, energy scheduling, and remote monitoring.
Renewable Energy Integration
Stores excess solar or wind energy, improving self-consumption and reducing reliance on the utility grid.
Technical Highlights
- Battery Chemistry: LiFePO₄ (LFP)
- Cell Capacity: 314Ah
- High Voltage Modular Design
- Intelligent BMS Integration
- Long Cycle Life
- High Charge/Discharge Efficiency
- Low Self-discharge Rate
- Wide Operating Temperature Range
- Multiple Communication Protocols (CAN / RS485 / Modbus)
- Compatible with Major PCS & Inverter Brands
Typical Applications
The 314Ah High Voltage Lithium Battery is designed to support a wide range of energy storage applications, delivering reliable, efficient, and scalable power for commercial, industrial, and residential energy systems. Whether integrated into off-grid installations, grid-connected projects, or backup power solutions, it provides stable energy storage with long service life and intelligent battery management.
Commercial & Industrial Off-Grid Energy Storage
Designed for locations with limited or no access to the utility grid, the 314Ah high-voltage lithium battery provides reliable power storage for standalone commercial and industrial energy systems.
Ideal for:
- Mining sites
- Remote factories
- Agricultural facilities
- Construction projects
- Islands and remote communities
Benefits:
- Ensure 24/7 power availability
- Reduce dependence on diesel generators
- Maximize solar energy utilization
- Lower fuel and operating costs
- Support sustainable off-grid operations
Commercial & Industrial Grid-Tied Energy Storage
For businesses connected to the utility grid, the battery helps optimize electricity consumption and improve energy efficiency.
Ideal for:
- Manufacturing plants
- Industrial parks
- Shopping malls
- Office buildings
- Warehouses
- Hotels
Benefits:
- Peak shaving and load shifting
- Reduce electricity demand charges
- Increase solar self-consumption
- Improve energy efficiency
- Enhance return on investment (ROI)
Commercial & Industrial Backup Power Systems
Critical facilities require uninterrupted electricity to maintain continuous operations. The battery delivers fast-response backup power during grid failures.
Ideal for:
- Hospitals
- Data centers
- Telecommunications facilities
- Financial institutions
- Government buildings
- Critical manufacturing lines
Benefits:
- Instant backup during outages
- Stable power supply for sensitive equipment
- Minimize production downtime
- Protect valuable assets
- Improve business continuity
Residential Off-Grid Solar Energy Storage
The battery is an ideal solution for homeowners seeking complete energy independence in areas without reliable grid access.
Ideal for:
- Rural homes
- Vacation houses
- Remote cabins
- Farms
- Small communities
Benefits:
- Store solar energy for day and night use
- Reliable electricity without grid dependence
- Quiet, clean alternative to diesel generators
- Low maintenance and long service life
- Flexible capacity expansion
Residential Hybrid Solar Energy Storage
For grid-connected homes, the battery integrates seamlessly with hybrid solar systems to improve energy efficiency and provide backup protection.
Ideal for:
- Residential solar installations
- Smart homes
- Villas
- Apartment communities
Benefits:
- Store excess solar energy
- Reduce household electricity bills
- Backup power during outages
- Maximize renewable energy usage
- Intelligent energy management for daily optimization
Why This Battery Fits Every ESS Scenario
Thanks to its 314Ah LiFePO₄ cells, intelligent Battery Management System (BMS), modular high-voltage architecture, and long cycle life, this battery is suitable for a wide range of Battery Energy Storage System (BESS) applications. From commercial and industrial facilities to residential solar projects, it provides a reliable, scalable, and future-ready energy storage solution that supports the transition to cleaner and more resilient power systems.
FAQs
1. Why is the 314Ah lithium battery popular for large energy storage systems?
The 314Ah design provides higher energy density and larger storage capacity, reducing the number of battery modules required in large projects.
2. Is the 314Ah high voltage battery suitable for solar farms?
Yes.Yes. It is designed for commercial and industrial solar energy storage, including solar farms and microgrid systems.
3. Can the 314Ah battery support continuous high-power output?
Yes. The system is built for stable high-power discharge performance in demanding applications.
4. Is the battery suitable for high voltage energy storage systems?
Yes. It is specially designed for high voltage applications, improving energy efficiency and inverter compatibility.
5. How does the 314Ah battery improve project scalability?
Its modular cabinet design allows flexible system expansion for different energy storage capacities.
6. Why do commercial users prefer 314Ah lithium batteries?
Commercial users value the high capacity, long cycle life, lower maintenance requirements, and efficient energy management capabilities.
